• 一、Feature


◆ Modular design, SMT process, high-performance switching power supply

◆ Five control methods are available:

0, two-way relay alarm

1. Relay J1 alarm output; relay J2 contact PID output

2. Two relay alarm outputs; one SSR level contactless PID output

3. Two relay alarm outputs; one SSR level difference control output

4. Relay J1 alarm output; relay J2 hysteresis control output

◆ The meter can display the temperature value in degrees Celsius or Fahrenheit

◆ Super strong PID auto-tuning function, automatically adapt to the controlled object, especially suitable

Incubator, heating furnace, etc.

• Two、Technical parameters


• 1. Working power: AC / DC85 ～ 260V (other power can be customized)

• 2. Input signal: thermocouple: T, R, J, B, S, K, E, WRe3-WRe25

• Thermal resistance: Pt100, Cu50

• 3. Power consumption: less than 2W

• 4. Sampling rate: 4 times / second

• 5. Display range: full range of input signal

• 6. Accuracy: 0.2% FS ± 1 word

• 7. SSR level: DC 8V / 30mA

• 8. Contact capacity: AC250V / 3A; DC24V / 5A

• 9. Operating environment: 0 ～ 50 ℃; ≤ 85% RH
